24V 3.5kW 48V 5.5kW Off Grid Hybrid Solar Inverter with MPPT

Name: 24V 3.5kW 48V 5.5kW Off Grid Hybrid Solar Inverter with MPPT
Brand: Shenzhen First Tech Co., Ltd.
SKU: EM (PV60-500VDC) 550048L
Price: 350.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: 1stess

Certification: CE, IEC

Model Number: EM (PV60-500VDC) 550048L

Document: EM1.5-6.2.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Price: To be negotiated

Packaging Details: carton box

Delivery Time: 30 days

Payment Terms: L/C,T/T

Supply Ability: 2000 pieces per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      6.2KW Off Grid Hybrid Solar Inverter, 48V Off Grid Hybrid Solar Inverter


Charging Mode:	MPPT	Operating Temperature:	-10°C To 50°C
Inverter Type:	Off Grid Inverter	Frequency:	50Hz/60Hz
Output Voltage:	48VDC	Communication Interface:	RS232+RS485

Charging Mode:	MPPT
Operating Temperature:	-10°C To 50°C
Inverter Type:	Off Grid Inverter
Frequency:	50Hz/60Hz
Output Voltage:	48VDC
Communication Interface:	RS232+RS485

Description

24V 3.5kW 48V 5.5kW Off Grid Hybrid Solar Inverter with MPPT

Single Phase Hybrid Inverter Pure Sine Wave Off Grid Solar Inverter

Key Features

Lithium battery activation function by PV or Utility
Compatible work with LiFePO4 battery via RS485
Pure sine wave output
Power factor 1.0
PV input voltage range: 60VDC-500VDC
Built-in MPPT (60A/100A/120A)
Capable to work without battery
Detachable dust cover for harsh environments
WiFi remote monitoring (optional)
Multiple output priority modes: UTL, SOL, SBU, SUB
EQ function to optimize battery performance and extend lifecycle

Technical Specifications

Attribute	Value
Charging Mode	MPPT
Operating Temperature	-10°C to 50°C
Inverter Type	Off Grid inverter
Frequency	50Hz/60Hz
Output Voltage	48VDC
Communication Interface	RS232+RS485

Model Comparison

Model Number	EM3500-24L	EM5500-48L	EM6200-48L
Place of Origin	China	China	China
Mounting Method	Wall Bracket	Wall Bracket	Wall Bracket
Nominal Battery Voltage	24VDC	48VDC	48VDC
Lithium Battery Activation	YES (By PV or Utility)	YES (By PV or Utility)	YES (By PV or Utility)
Nominal Voltage	230VAC	230VAC	230VAC
Lithium Battery Communication	YES (RS485)	YES (RS485)	YES (RS485)
Frequency	50/60Hz	50/60Hz	50/60Hz
Waveform	Pure Sine wave	Pure Sine wave	Pure Sine wave
Solar Charger Type	MPPT	MPPT	MPPT
Communication Interface	RS232+RS485	RS232+RS485	RS232+RS485
PV Array MPPT Voltage Range	60VDC~500VDC	60VDC~500VDC	60VDC~500VDC
Surge Power	7000VA	11000VA	1240VA
Size	358295100mm	438295105mm	438295105mm
Weight	7kg	9kg	9kg
Operating Temperature Range	-10°C to 50°C	-10°C to 50°C	-10°C to 50°C
