48V 6.2kW Hybrid Solar Inverter with MPPT Pure Sine Wave

Name: 48V 6.2kW Hybrid Solar Inverter with MPPT Pure Sine Wave
Brand: Shenzhen First Tech Co., Ltd.
SKU: M (PV60-500VDC)6200-48PL
Price: 350.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: 1stess

Certification: CE, IEC

Model Number: M (PV60-500VDC)6200-48PL

Document: M6200-48L.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Price: To be negotiated

Packaging Details: carton box

Delivery Time: 30 days

Payment Terms: L/C,T/T

Supply Ability: 2000 pieces per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      Three Phase 5Kw Hybrid Inverter, Three Phase Solar Inverter 6Kw, 10Kw Hybrid Solar Inverter


Charging Mode:	MPPT	Operating Temperature:	-10°C To 50°C
Inverter Type:	Hybrid Solar Inverter	Frequency:	50Hz/60Hz
Rated Battery Voltage:	48V	Size:	450300130mm

Charging Mode:	MPPT
Operating Temperature:	-10°C To 50°C
Inverter Type:	Hybrid Solar Inverter
Frequency:	50Hz/60Hz
Rated Battery Voltage:	48V
Size:	450300130mm

Description

48V 6.2kW Hybrid Solar Inverter with MPPT Pure Sine Wave

48V 6.2kW Off Grid Solar Inverter

Single Phase 6200W 6.2KVA Hybrid Inverter with Pure Sine Wave and MPPT Technology

Key Specifications

Attribute	Value
Charging Mode	MPPT
Operating Temperature	-10°C to 50°C
Inverter Type	Hybrid Solar Inverter
Frequency	50Hz/60Hz
Rated Battery Voltage	48V
Size	450×300×130mm

Product Features

Compatible with LiFePO4 batteries
Parallel operation capability - up to 12 units in 1-phase or 3-phase configuration
Direct plug WiFi dongle supported
Pure sine wave output
Power factor 1.0
PV input 500Vdc maximum
Built-in MPPT 120A
Capable of working without battery
Detachable dust cover for harsh environments
WiFi remote monitoring (optional)
Multiple output priority modes: UTL, SOL, SBU, SUB
EQ function to optimize battery performance and extend lifecycle

Model: M6200-48PL
Place of Origin: China
Mounting Method: Wall Bracket
Frequency: 50/60Hz
Capacity: 6.2KVA/6.2KW
Parallel Capability: Yes, up to 12 units
Nominal Voltage: 230VAC
Waveform: Pure Sine wave
Battery Voltage: 48VDC
Solar Charger Type: MPPT
Max PV Array Power: 6500W
Max Solar Charge Current: 120A
Size: 450×300×130mm
Weight: 9.6kg
Communication Interface: RS232/RS485

Product Images
