Off Grid Hybrid Solar Inverter 6.2KW No Battery Required Built-in 120A MPPT Charger

Name: Off Grid Hybrid Solar Inverter 6.2KW No Battery Required Built-in 120A MPPT Charger
Brand: Shenzhen First Tech Co., Ltd.
SKU: EM-T (PV60-500VDC) 5500-48PL
Price: 350.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: 1stess

Certification: CE, IEC

Model Number: EM-T (PV60-500VDC) 5500-48PL

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Price: To be negotiated

Packaging Details: carton box

Delivery Time: 30 days

Payment Terms: L/C,T/T

Supply Ability: 2000 pieces per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Off Grid Hybrid Solar Inverter 6.2KW, Solar Inverter with 120A MPPT Charger, Hybrid Solar Inverter no battery required


Charging Mode:	MPPT	Operating Temperature:	-10°C To 50°C
Inverter Type:	Off Grid Inverter	Frequency:	50Hz/60Hz
Nominal Output Voltage:	220VAC/230/240VAC	Communication Interface:	RS232+RS485+ External CT Port
Acceptable Input Voltage Range:	170-280VAC Or 90-280VAC	Size:	450300130mm
Waveform:	Pure Sine Wave	Output Current:	120A
Weight:	12kg

Charging Mode:	MPPT
Operating Temperature:	-10°C To 50°C
Inverter Type:	Off Grid Inverter
Frequency:	50Hz/60Hz
Nominal Output Voltage:	220VAC/230/240VAC
Communication Interface:	RS232+RS485+ External CT Port
Acceptable Input Voltage Range:	170-280VAC Or 90-280VAC
Size:	450300130mm
Waveform:	Pure Sine Wave
Output Current:	120A
Weight:	12kg

Description

Off Grid Hybrid Solar Inverter 6.2KW No Battery Required Built-in 120A MPPT Charger

Off Grid Hybrid Solar Inverter 6.2KW

No Battery Required with Built-in 120A MPPT Charger

Key Features

6.2KW Pure Sine Wave Output - Rated power 6.2KVA/6.2KW, surge up to 12400VA, power factor 1.0, suitable for all kinds of household and office appliances.
Flexible Parallel Expansion - Supports up to 12 units in parallel for single-phase or three-phase configurations, easily scaling from small homes to commercial sites.
High PV Input Voltage (500Vdc Max) - MPPT voltage range 60~450Vdc, compatible with high-voltage solar panels for improved system efficiency.
Built-in 120A High-Current MPPT Controller - Max solar input current 27A, max solar charge current 120A, enabling fast and efficient PV harvesting.
Perfect Li-ion/LiFePO4 Compatibility - Supports lithium battery activation (via PV or utility) and features RS485 communication for BMS integration.
Multiple Output Priority Modes - Selectable UTL, SOL, SBU, and SUB modes to adapt to different usage scenarios.
Battery-less Operation - Can run without a battery, reducing initial investment and increasing flexibility.

Advanced Performance Features

Feature	Description
Wide AC Input Range	170-280VAC (PC mode) / 90-280VAC (home appliance mode), adapts to unstable grids.
Auto Frequency Sensing	Automatically detects 50/60Hz.
High Efficiency	Peak efficiency up to 94%.
Fast Transfer Time	10ms (PC mode) / 20ms (home appliance mode) for uninterrupted power to critical loads.
Comprehensive Protection	Overload protection (5s @ ≥140% load; 10s @ 110%~140% load), overcharge protection (63VDC).
Multiple Communication Ports	RS232 & RS485, plus plug-and-play WiFi Dongle support for remote monitoring.
Detachable Dust Cover	Protects against harsh environments, extending product lifespan.
Equalization (EQ) Function	Optimizes battery performance and prolongs battery life.

Technical Specifications

Specification	GM5500-48PL	GM6200-48PL
Phase Configuration	1-Phase In / 1-Phase Out	1-Phase In / 1-Phase Out
Maximum PV Input Power	5500W	6500W
Nominal Output Voltage	220/230/240V AC	220/230/240V AC
Output Waveform	Pure Sine Wave	Pure Sine Wave
Battery Voltage	48V DC	48V DC
Communication Ports	RS232 + RS485 + External CT Port	RS232 + RS485 + External CT Port
Maximum Solar Charge Current	100A	120A
Dimensions (D x W x H)	448 × 315 × 122 mm	450 × 300 × 130 mm
