3.5KW Hybrid Solar Inverter 24V MPPT Pure Sine Wave Off Grid

Name: 3.5KW Hybrid Solar Inverter 24V MPPT Pure Sine Wave Off Grid
Brand: Shenzhen First Tech Co., Ltd.
SKU: EM (PV60-500VDC) 3500-24L
Price: 350.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: 1stess

Certification: CE, IEC

Model Number: EM (PV60-500VDC) 3500-24L

Document: EM1.5-6.2.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Price: To be negotiated

Packaging Details: carton box

Delivery Time: 30 days

Payment Terms: L/C,T/T

Supply Ability: 2000 pieces per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          3.5KW Off Grid Hybrid Solar Inverter, 1.5kw Off Grid Hybrid Solar Inverter, 24V Off Grid Hybrid Solar Inverter


Charging Mode:	MPPT	Operating Temperature:	-10°C To 50°C
Inverter Type:	Off Grid Inverter	Frequency:	50Hz/60Hz
Output Voltage:	220VAC/230VAC	Communication Interface:	RS232+RS485
Input Voltage:	230VAC	Size:	385295100mm
Waveform:	Pure Sine Wave	Output Frequency:	50/60Hz
Weight:	7kg

Charging Mode:	MPPT
Operating Temperature:	-10°C To 50°C
Inverter Type:	Off Grid Inverter
Frequency:	50Hz/60Hz
Output Voltage:	220VAC/230VAC
Communication Interface:	RS232+RS485
Input Voltage:	230VAC
Size:	385295100mm
Waveform:	Pure Sine Wave
Output Frequency:	50/60Hz
Weight:	7kg

Description

3.5KW Hybrid Solar Inverter 24V MPPT Pure Sine Wave Off Grid

Single Phase 3.5KW Hybrid Solar Inverter 1.5KW 2.5KW Solar Hybrid Inverter Pure Sine Wave Off Grid 1500W 2500W 3500W 24V Solar Inverter with MPPT

Product Specifications

Attribute	Value
Charging Mode	MPPT
Operating Temperature	-10°C To 50°C
Inverter Type	Off Grid inverter
Frequency	50Hz/60Hz
Output Voltage	220VAC/230VAC
Communication Interface	RS232+RS485
Input Voltage	230VAC
Size	385295100mm
Waveform	Pure Sine wave
Output Frequency	50/60Hz
Weight	7kg

Key Features

Lithium battery activation function by PV or Utility
Compatible work with lifepo4 battery via Rs485
PVInput 500Vdc Max
Built-in MPPT60A/100A/120A
Detachable dust cover for harsh environment
Wifi remote monitoring optional
Support multiple output priority: UTL, SOL, SBU, SUB
EQ function to optimize battery performance and extend lifecycle

Model Comparison

Model Number	EM1500-24	EM2500-24	EM3500-24L
Place of Origin	China	China	China
Mounting Method	Wall Bracket	Wall Bracket	Wall Bracket
Nominal Battery Voltage (V)	24VDC	24VDC	24VDC
Lithium Battery activation	YES (By PV only)	YES (By PV only)	YES (By PV or Utility)
Nominal Voltage	230VAC	230VAC	230VAC
Lithium Battery communication	YES(RS485)	YES(RS485)	YES(RS485)
Frequency	50/60Hz	50/60Hz	50/60Hz
Waveform	Pure Sine wave	Pure Sine wave	Pure Sine wave
Solar Charger Type	MPPT	MPPT	MPPT
Communication Interface	RS232+RS485	RS232+RS485	RS232+RS485
PV Array MPPT Voltage Range	60VDC~500VDC	60VDC~500VDC	60VDC~500VDC
Surge Power	3000VA	5000VA	7000VA
Size	358295100mm	358295100	358295100mm
Weight	6kg	6.5kg	7kg
Operating Temperature Range	(-10°C to 50°C)	(-10°C to 50°C)	(-10°C to 50°C)
